PNOZ s6.1
Operating Manual PNOZ s6.1
21692-EN-08
6
Preparing for operation
} Supply voltage
Supply voltage AC DC
A1 L
A2
N
S14
A1 L+
A2
L-
} Input circuit
Input circuit Single-channel Dual-channel
Two-hand pushbuttons
with detection of shorts
across contacts
S23
S13
S14
S24
S1
S2
Simultaneity monitoring in
safety gate applications
with automatic start after the
safety gate is closed
S1
S2
S14
S13
S24
S23
*
ATTENTION!
*The unit starts automatically when the E-STOP / safety gate device is re-
leased. Use external circuit measures to prevent an unexpected restart.
} Feedback loop
Feedback loop
Contacts from external con-
tactors K5 K6
K5
L1
N
K6
S24
13 (23,33)
S34
14 (24,34)
