PNOZ s6.1
Operating Manual PNOZ s6.1
21692-EN-08
11
Technical details
General 750126 750156 751126 751156
Approvals CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
Electrical data 750126 750156 751126 751156
Supply voltage
Voltage 24 V 48 - 240 V 24 V 48 - 240 V
Type DC AC/DC DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply
(AC)
– 7,0 VA – 7,0 VA
Output of external
power supply
(DC)
3,5 W 3,5 W 3,5 W 3,5 W
Frequency range
AC
– 50 - 60 Hz – 50 - 60 Hz
Residual ripple
DC
20 % 20 % 20 % 20 %
Continuous duty 100 % 100 % 100 % 100 %
Max. overall cable
resistance Rlmax
per input circuit
30 Ohm 30 Ohm 30 Ohm 30 Ohm
Voltage at
Input circuit DC 24,0 V 24,0 V 24,0 V 24,0 V
Feedback loop
DC
24,0 V 24,0 V 24,0 V 24,0 V
Current at
Feedback loop 15,0 mA 15,0 mA 15,0 mA 15,0 mA
N/O contact 20 mA 20 mA 20 mA 20 mA
Number of output
contacts
Instantaneous
safety contacts
(N/O)
3 3 3 3
Auxiliary contacts
(N/C)
1 1 1 1
Min. unit fuse protec-
tion
1,00 A 1,00 A 1,00 A 1,00 A
Max. unit fuse pro-
tection F1
Max. cable cross
section
Max. cable cross
section
Max. cable cross
section
Max. cable cross
section
Two-hand control re-
lay type
In accordance
with the standard
EN 574 EN 574 EN 574 EN 574
Type III A III A III A III A
Inputs 750126 750156 751126 751156
Number 2 2 2 2
