PNOZ s6.1
Operating Manual PNOZ s6.1
21692-EN-08
15
Mechanical data 750126 750156 751126 751156
Material
Bottom PC PC PC PC
Front PC PC PC PC
Top PC PC PC PC
Cross section of ex-
ternal conductors
with screw terminals
1 core flexible 0,25 - 2,50 mm², 24
- 12 AWG
0,25 - 2,50 mm², 24
- 12 AWG
– –
2 core with the
same cross sec-
tion, flexible with
crimp connectors,
no plastic sleeve
0,25 - 1,00 mm², 24
- 16 AWG
0,25 - 1,00 mm², 24
- 16 AWG
– –
2 core with the
same cross sec-
tion, flexible with-
out crimp connec-
tors or with TWIN
crimp connectors
0,20 - 1,50 mm², 24
- 16 AWG
0,20 - 1,50 mm², 24
- 16 AWG
– –
Torque setting with
screw terminals
0,50 Nm 0,50 Nm – –
Connection type Screw terminal Screw terminal Spring-loaded ter-
minal
Spring-loaded ter-
minal
Mounting type plug in plug in plug in plug in
Cross section of ex-
ternal conductors
with spring-loaded
terminals: flexible
with/without crimp
connector
– – 0,20 - 2,50 mm², 24
- 12 AWG
0,20 - 2,50 mm², 24
- 12 AWG
Spring-loaded termi-
nals: Terminal points
per connection
– – 2 2
Stripping length – – 9 mm 9 mm
Dimensions
Height 98,0 mm 98,0 mm 100,0 mm 100,0 mm
Width 22,5 mm 22,5 mm 22,5 mm 22,5 mm
Depth 120,0 mm 120,0 mm 120,0 mm 120,0 mm
Weight 185 g 205 g 185 g 205 g
The standards current on 2011-06 apply.
