PNOZ s6.1
Operating Manual PNOZ s6.1
21692-EN-08
13
Relay outputs
750126
750156
751126
751156
Contact fuse protec-
tion, external safety
contacts
In accordance
with the standard
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
Blow-out fuse,
quick
10 A
6 A
10 A
6 A
Blow-out fuse,
slow
6 A
4 A
6 A
4 A
Circuit breaker,
24V AC/DC, char-
acteristic B/C
6 A
4 A
6 A
4 A
Contact fuse protec-
tion, external auxilia-
ry contacts
Blow-out fuse,
quick
10 A
6 A
10 A
6 A
Blow-out fuse,
slow
6 A
4 A
6 A
4 A
Circuit breaker,
24 V AC/DC,
characteristic B/C
6 A
4 A
6 A
4 A
Contact material
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
Conventional ther-
mal current while
loading several
contacts
750126
750156
751126
751156
Ith per contact at UB
AC
Conv. therm. cur-
rent with 1 con-
tact
–
6,00 A
–
6,00 A
Conv. therm. cur-
rent with 2 con-
tacts
–
6,00 A
–
6,00 A
Conv. therm. cur-
rent with 3 con-
tacts
–
4,50 A
–
4,50 A
Ith per contact at UB
DC
Conv. therm. cur-
rent with 1 con-
tact
6,00 A
6,00 A
6,00 A
6,00 A
Conv. therm. cur-
rent with 2 con-
tacts
6,00 A
6,00 A
6,00 A
6,00 A
Conv. therm. cur-
rent with 3 con-
tacts
6,00 A
4,50 A
6,00 A
4,50 A
