 Align the deviating mirror to ca. 45° to the optical path. PSEN op
Protective Column 2-4/1 allows regulation around the vertical axis
by +/- 5° (s. section "Levelling and angular adjustment of the
plates").
 Position the laser pointer at the upper part of the transmitter unit
and align the unit so that the laser beam is horizontal in the
middle of the first deviating mirror. The height of the laser pointer
and the height where the pointer hits have to be identical.
 Repeat the procedure and align the laser pointer at the bottom
part of the unit. Repeat these steps several times, if necessary.
 Align the first deviation mirror so that the laser beam hits the
second deviating mirror in the position described before.
NOTICE
The laser pointer has mechanical tolerances when combined with PSEN op
Protective Column 2-4/1. The tolerances can be compensated by levelling and
angular adjustments of the protective columns and the laser pointer. Do not
compensate the tolerances by changing the deviating mirror position.
