CardioPerfect Workstation
ABP Module - User Manual
DIR 80012332 Ver. E 35 / 40
Error Description
1 Unknown error
2 This can indicate one of the following problems:
After 2 seconds the pulse has not reached the falling level.
Heart frequency has not reached its defined range.
Variation of the heart frequency is too large.
Less than 4 measurements were taken.
The rising level was not reached within 2 seconds after the falling level.
Pulse bandwidth is out of range.
Movement artifact.
Maximum number of beats encountered in a stage.
3 This can indicate one of the following problems:
The heart frequency was out of range in more than 3 pressure stages.
The difference between systole and diastole was too small.
The systole is considerably bigger than the pump pressure.
An oscillation value was smaller than the start or end value.
The pulse bandwidth is smaller than at start or end point.
The MAP is out of range.
The systole is out of range.
The diastole is too large.
The number of stages is too large.
The oscillation value is too large.
The total time is too long.
A function took too much time.
4 The battery voltage is too low.
5 No cuff was detected.
6 Too many measurements were taken
-or-
No memory was available in EEPROM
7 No measurements are available.
-or-
The measurements were stopped.
8 Hardware failure
-or-
Error at zero alignment or pumping started unexpectedly.
Note : The codes mentioned above are the codes as listed by the software. The can differ
from the codes in the LCD display of the ABPM 6100. The latter ones are for reference
only, the error codes used in the software module as listed above are the error codes which
correctly identify the possible error status.
