CardioPerfect Workstation
ABP Module - User Manual
DIR 80012332 Ver. E 21 / 40
The measurements slider only gives exact values for 30 minutes intervals.
Compare ABP tests of the same patient
In the Trends view, you can compare the current ABP record with a previous recorded test
of the same patient.
To make a comparison:
1. Right click on the graph.
2. In the shortcut menu, click Comparison.
3. In the Comparison dialog box select the test with which you want to compare
the current test and click OK.
4. The graphs for both tests are shown in the Trends view window. To return to
the current test, click Comparison in the shortcut menu and click on the
selected test.
Slider Exact value for points
at slider position
