1. This area displays the patient summary.
2. This area allows you to change the duration of the displayed patient measurements and alarms.
Grab the center of the blue timeline bar and slide it left or right to select a different time interval. Grab and slide
either of the endpoints to widen or narrow the time interval.
3. This area displays the history of the patient's episodic measurements.
4.
Click to open the display options window. In this window, you can choose which vital signs and which
modifiers are displayed.
Click to print the Flow Sheet.
34 Patient Review Welch Allyn Connex ® Central Station
