Page 31
SP-2000/X-Y
Operation
User Manual
2-3
Orientation
As an aid in operating and maintaining the SP-2000/X-Y, it is useful to define
the orientation of the pedestal by the points of the compass - North, South, East
and West.
As shown in the picture above, the main control panel is on the South side of the
pedestal, the “front” wheel of the pedestal is on the North side and the other two
wheels are on the East and West sides.
South
West
East
North
