Battery Max Amps Out: Set for maximum supply battery current draw. If the charge
rate is set higher than the input current allows, the PowerLab 6 will draw no more than
the level set here, which may limit output current to the pack. If Battery Max Amps
Out
is set too high, the battery’s output voltage may drop below the Battery Low
Voltage Out
setting and charging will stop and the input battery could be damaged
from excessive current draw.
Enable Regenerative Discharge: If checked, pack discharge energy (up to
40A/1000W) is sent to supply battery during discharge cycles. If not checked,
discharge is dissipated internally (limited to 50W).
Regen. Amps IN to Pb: Set to maximum regenerative current to supply battery.
Consider battery chemistry and size when setting this value. For example, Lead Acid
batteries should not be charged at a rate higher than C/8.
CAUTION:
An excessively high and sustained regenerative current back into
the supply battery can harm the battery and reduce its useful life. Always
follow the input battery manufacturer’s recommendations when setting up for
regenerative discharge.
Regen. Charge Voltage IN to Pb: Set to maximum regenerative voltage applied to
supply battery. For a 24V supply battery, PowerLab 6 will automatically double the
value set here. If the regenerative voltage reaches the value set here, PowerLab 6
switches to internal discharge to prevent the supply battery from being overcharged.
Expansion Channel section
If multiple PowerLabs are operating in
, select the channel
from which supply data will be displayed.
