SPECIFICATION
RSP-2000-12 RSP-2000-24 MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE Note.5
FREQUENCY RANGE
POWER FACTOR (Typ.)
EFFICIENCY (Typ.)
INPUT
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
AC CURRENT (Typ.) Note.5
12V 24V
100A 80A
0 ~ 100A 0 ~ 80A
1200W 1920W
150mVp-p
10.5 ~ 14V
200mVp-p
21 ~ 28V
2.0% 1.0%
1.0%
1.0%
1500ms, 60ms/230VAC at full load
16ms/230VAC at 75% load 10ms/230VAC at full load
90 ~ 264VAC 127 ~ 370VDC
47 ~ 63Hz
0.97/230VAC at full load
87%
COLD START 50A
13A/115VAC 7A/230VAC 16A/115VAC 10A/230VAC 16A/115VAC 10A/230VAC
<2mA / 240VAC
RSP-2000-48
48V
42A
0 ~ 42A
2016W
300mVp-p
42 ~ 56V
1.0%
0.5% 0.5%
0.5% 0.5%
Universal AC input / Full range
Built-in 5V/0.3A, 12V/0.8A auxiliary power
Built-in active PFC function, PF>0.97
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan with fan speed control
Output voltage can be trimmed between 40~115% of the rated output voltage
1U low profile 41mm
Active current sharing up to 8000W(3+1)
Built-in remote sense function
DC OK signal, OTP alarm signal
3 years warranty
High Power density 21.4W/inch
Built-in remote ON-OFF control
3
RIPPLE & NOISE (max.) Note.2
VOLTAGE TOLERANCE Note.3
90.5% 92%
Protection type : Constant current limiting, unit will shut down o/p voltage after 5 sec. re-power on to recover
OVER TEMPERATURE
OVERLOAD
OVER VOLTAGE
105 ~ 125% rated output power
14.7 ~ 17.5V
Protection type : Shut down o/p voltage, re-power on to recover
80 5 (TSW1) detect on heatsink of power bridge 75 5 (TSW2) detect on heatsink of o/p diode
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
29.5 ~ 35V 57.6 ~ 67.2V
PROTECTION
2000W Single Output Power Supply
Features :
R S P - 2 0 0 0
s e r i e s
DC OK SIGNAL
REMOTE SENSE
REMOTE ON/OFF CONTROL
AUXILIARY POWER
The isolated TTL signal out, refer to function manual
Compensate voltage drop on the load wiring up to 0.5V, refer to function manual
By electrical signal or dry contact Power ON:open Power OFF:short, refer to function manual
5V @ 0.3A, 12V @ 0.8A
FUNCTION
Adjustment of output voltage, possible between 40 ~ 115% of rated output, refer to function manual
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
-35 ~ +70 (Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-40 ~ +85 , 10 ~ 95% RH
0.03%/ (0 ~ 50 )
ENVIRONMENT
OUTPUT VOLTAGE TRIM
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
File Name:RSP-2000-SPEC 2011-12-27
SAFETY STANDARDS
WITHSTAND VOLTAGE
UL60950-1, TUV EN60950-1 approved
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE
MTBF
DIMENSION
PACKING
OTHERS
46.3Khrs min. MIL-HDBK-217F (25 )
295*127*41mm (L*W*H)
SAFETY &
EMC
(Note 4)
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH
1.95Kg; 6pcs/12.7Kg/1.15CUFT
Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), heavy industry level, criteria A
Compliance to EN55022 (CISPR22) Conduction Class B, Radiation Class A ; EN61000-3-2,-3
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Derating may be needed under low input voltages. Please check the derating curve for more details.
6. Under parallel operation ripple of the output voltage may be higher than the SPEC at light load condition. It will go back to normal ripple level once the
output load is more than 5%.
EMC IMMUNITY
EMC EMISSION
