ProgressiveRC RSP-1000 series - Manual

SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE Note.5
FREQUENCY RANGE
EFFICIENCY (Typ.) INPUT
FUNCTION
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVER TEMPERATURE
WORKING TEMP.
CURRENT SHARING(CS) Note.7
OUTPUT VOLTAGE TRIM Note.6
DC OK SIGNAL
REMOTE ON/OFF CONTROL Note.6
AUXILIARY POWER(AUX)
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
MTBF
DIMENSION OTHERS
NOTE
PACKING
OVERLOAD
OVER VOLTAGE
AC CURRENT (Typ.)
300ms, 50ms at full load
16ms/230VAC 16ms/115VAC at full load
90 ~ 264VAC 127 ~ 370VDC
47 ~ 63Hz
12A/115VAC 6A/230VAC
25A/115VAC 40A/230VAC
<2.0mA / 240VAC
105 ~ 125% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
13.8 ~ 16.8V 17 ~ 20.5V 27.6 ~ 32.4V 31 ~ 36.5V 56.6 ~ 66.2V
Protection type : Shut down o/p voltage, re-power on to recover
85 5 (TSW2 ) detect on heatsink of O/P diode; 75 5 (TSW1 ) detect on heatsink of power transistor
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
-20 ~ +60 (Refer to output load derating curve)
Power on : short between on/off(pin6) & -S(pin2) on CN50 Power off : open between on/off(pin6) & -S(pin2) on CN50
The TTL signal out, PSU turn on = 3.3 ~ 5.6V ; PSU turn off = 0 ~ 1V
Adjustment of output voltage is possible between 40 ~ 110% of rated output
Please refer to function manual
5V @ 0.5A (+5%, -8%)
20 ~ 90% RH non-condensing
-40 ~ +85 , 10 ~ 95% RH
0.02%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
35K hrs min. MIL-HDBK-217F (25 )
295*127*41mm (L*W*H)
1.95Kg; 6pcs/12.7Kg/0.99CUFT
83% 85% 88% 88% 90%
0.5% 0.5% 0.5% 0.5% 0.5%
0.5% 0.5% 0.5% 0.5% 0.5%
1.0% 1.0% 1.0% 1.0% 1.0%
150mVp-p
10 ~ 13.5V
150mVp-p
13.5 ~ 16.5V
150mVp-p
20 ~ 26.4V
150mVp-p
24 ~ 30V
150mVp-p
43 ~ 55V
12V
60A
0 ~ 60A
720W
15V
50A
0 ~ 50A
750W
24V
40A
0 ~ 40A
960W
27V
37A
0 ~ 37A
999W
48V
21A
0 ~ 21A
1008W
RSP-1000-12 RSP-1000-15 RSP-1000-24 RSP-1000-27 RSP-1000-48
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Derating may be needed under low input voltages. Please check the derating curve for more details.
6. The power supply unit will have no output if the shorting connector is not assembled. It contains two shorting wires: one is from on/off(pin6) to -s(pin2)
and the other is from Vco(pin8) to Vca(pin10). Please refter to function manual for details.
7. In parallel connection, maybe only one unit operate if the total output load is less than 5% of rated load condition.
8. Please consult MEAN WELL for applications of more units connecting in parallel.
POWER FACTOR (Typ.) 0.95/230VAC 0.98/115VAC at full load
SAFETY STANDARDS
HARMONIC CURRENT
EMS IMMUNITY
UL60950-1, TUV EN60950-1 approved
Compliance to EN55022 (CISPR22)
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A
1000W Single Output Power Supply
R S P - 1 0 0 0
s e r i e s
RIPPLE & NOISE (max.) Note.2
VOLTAGE TOLERANCE Note.3
EMI CONDUCTION & RADIATION
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
ENVIRONMENT
SAFETY &
EMC
(Note 4)
PROTECTION
Universal AC input / Full range
AC input active surge current limiting
Built-in 5V/0.5A auxiliary power
Built-in active PFC function, PF>0.95
Protections: Short circuit / Overload / Over voltage / Over temperature
Output voltage can be trimmed between 40 ~ 110% of the rated output voltage
Forced air cooling by built-in DC fan
Active current sharing up to 4000W(3+1)
DC OK Signal
Built-in remote ON-OFF control
Built-in remote sense function
3 years warranty
(Note.8)
High power density 10.7w/inch
1U low profile 41mm
3
Features :
..
