iCharger Synchronous Balance Charger/Discharger 4010DUO
- 23 -
 NiMH/NiCd Battery Discharge Setup
Select Program→Discharge to enter Discharge setup interface.
Note: 1. Regenerative mode has three modes available: OFF, To input, To channel. See more details on
Page38 Important Notes .
2. To channel Setup please see Page20 To channel Setup .

NiMH/NiCd Battery Discharge Safety Setup
Click " " to enter DISCHARGE SAFETY SETUP interface, see details about setting on Page20 LiPo/LiIo/LiFe
Battery Discharge Safety Setup .
 NiMH/NiCd Battery Cycle Setup
Select Program→Cycle to enter Cycle setup interface, see details about setting on Page21 LiPo/LiIo/LiFe Battery Cycle
Setup.
 Pb Battery Charge/Discharge Setup
After adding program, it will switch to Pb battery in Type option on the MEMORY SETUP interface. Set the number of
cells and capacity, after editing all parameters for program, click" "to save and return to the previous interface.
As shown in above picture, the program of Pb battery has the following modes: Charge, Discharge and Cycle.
 Pb Battery Charge Setup
Select Program→Charge to enter Charge setup interface.
Note: 1.The charger first charges with constant current (CC) according to the user setting then turns to
constant voltage (CV) when the charging voltage reaches the peak point. In the CV phase the
current gradually falls, and the charger will terminate charging when the current falls below
the percentage of the configured charge current.
2.Charge mode has Normal, Reflex two modes available, about the Reflex mode (Reflex) please
see Page38 Important Notes .
Discharge Current: 0.05A-40A; default: 2A
Discharge Voltage: 0.1V-40V; default: 0.1V
End Current: 1%-100%; default: 50%
Regenerative Mode: OFF (default), To input, To channel
Chg Current: 0.05A-40A; default: 2A
Chg Mode: Normal (default), Reflex
Chg End Current: 1%-50%; default: 10%
Chg Cell Volt: 2V/Cell-2.6V/Cell; Default: 2.4V/Cell
Cells: 1-15S; default: 6S
