R E L I A N C E S T O R M M A X I N S T A L L A T I O N M A N U A L
DRY GLAZED GASKET INSTALLATION (OPTIONAL)
3.1 a. Cut vertical GP-1015 gasket to D.L.O. plus 1 1/2".
b. Cut the horizontal GP-1015 gasket to D.L.O. plus 3/16".
c. Bed 2" at horizontal vertical intersections including the gasket reglet with Dow Corning 795 sealant.
d. Install vertical GP-1015 gasket into reglet using a vinyl roller. Begin at center work towards ends.
e. Install horizontal GP-1015 gasket next. Apply silicone on ends. Begin at center of horizontal.
Use a vinyl roller to ensure proper engagement.
2"
2"
HW-500 Horizontal
GP-1015 Dry Glazed Gasket
Apply Dow Corning 795
to seal gasket joint
Apply Dow Corning 795 sealant and push
gasket in to reglet then use roller to properly
engage the gasket
FIGURE 3.1a
