KTD-S0008-F Page 4 Specifications
JRexplus-DC User's Guide
3 Specifications
3.1 Functional Specifications
Processor: Intel ® ATOM ™ N270
512 kB L2 cache
1.6 GHz clock frequency
Northbridge: Intel ® 945GSE
533 MHz Front Side Bus (FSB)
One DDR2-533 unbuffered DDR-SDRAM (SODIMM form factor) up to 2 GB
Integrated Intel ® GMA950 graphic controller with dual independent display support
Southbridge: Intel ® ICH7M
Two channel Serial-ATA interface
Parallel-ATA PCI IDE controller
Eight USB channels (UHCI/EHCI) (seven channels available, one channel as PCI Express
MiniCard interface)
One LAN controller with LAN Connect Interface (LCI)
Two PCI Express ports (x1 lanes)
Integrated Intel ® High Definition audio controller (HD audio)
External PCI bus with 32 bit / 33 MHz operation (PCI V2.3 compliant)
Onchip Video Graphics Array (VGA): Intel ® GMA950
Intel ® Gen 3.5 graphics engine
Dynamic Video Memory Technology (DVMT 3.0)
DirectX 9.0c support
Low Voltage Differential Signaling (LVDS) 18 bit dual channel interface up to UXGA display
resolution
Intel ® Serial Digital Video Out (SDVO) with DVI monitor interface (maximal 160 MHz pixel
clock)
Analogue Video Graphics Array output (VGA/CRT) up to WUXGA resolution (DVI-I connector)
Onchip Parallel-ATA (P-ATA)
Supports PIO mode, Multiword DMA and Ultra DMA up to UDMA5
Compact Flash (CF) socket useable as master or slave
