Kontron JRexplus-DC - Manual (Page 60)

KTD-S0008-F Page 55 Setup Guide
JRexplus-DC User's Guide
22.5.5.4 SMBIOS Configuration Submenu
Feature Option Description
SMBIOS SMI Support Disabled
Enabled
SMI wrapper support for PnP function 50h-54h
22.5.5.5 Remote Access Configuration Submenu
Feature Option Description
Remote Access Disabled
Enabled
Enable or disable the remote connection
Serial Port Number COM1
COM2
Select the serial port for console redirection
Base Address, IRQ N / A Show the actual port settings
Serial Port Mode 115200,8,n,1
57600,8,n,1
38400,8,n,1
19200,8,n,1
9600,8,n,1
Select the serial port settings
Flow Control None
Hardware
Software
Select the flow control mode
Redirection after BIOS
POST
Disabled
Boot Loader
Always
Disabled = turns off redirection after POST
Boot Loader = redirection is enabled during POST and boot
process
Always = redirection is always enabled
Terminal Type ANSI
VT100
VT-UTF8
Define the target terminal type. VT-UTF8 adds some special
ESC-sequences to VT100
VT-UTF8 Combo Key
Support
Disabled
Enabled
Support for ANSI/VT100 terminals
Sredir Memory Display
Delay
No Delay
Delay 1 Sec
Delay 2 Sec
Delay 4 Sec
Gives the delay to display memory information
