KTD-S0008-F Page 46 Setup Guide
JRexplus-DC User's Guide
22.5.2.4 IDE Configuration Submenu
Feature Option Description
ATA/IDE Configuration Disabled
Compatible
Enhanced
The entry 'Enhanced' allow more detailed SATA settings
Legacy IDE Channels SATA Only
SATA Pri, PATA Sec
PATA Only
Only visible if 'ATA/IDE Configuration' is set to 'Compa-
tible'. Enable or disable the PATA or SATA controller
Configure SATA as Disabled
RAID
Only visible if 'Legacy IDE Channels' is set to 'PATA Only'
Configure SATA as IDE
RAID
AHCI
Only visible if 'ATA/IDE Configuration' is set to 'Enhanced'.
Configure the SATA controller in native (IDE), RAID or AHCI
mode
Configure SATA Channels Before PATA
Behind PATA Only visible if 'ATA/IDE Configuration' is set to 'Enhanced'
and 'Configure SATA as' is set to 'IDE'. Define the detection
order
8Primary IDE Master Submenu Display the status of autodetection
8Primary IDE Slave
Submenu Display the status of autodetection
8Secondary IDE Master
Submenu Display the status of autodetection
8Secondary IDE Slave Submenu Display the status of autodetection
8Third IDE Master Submenu Display the status of autodetection
8Third IDE Slave Submenu Display the status of autodetection
Hard Disk Write Protect Disabled
Enabled
Allow the write protection of harddisk devices. Only valid if
the device is accessed through the BIOS
IDE Detect Time Out (Sec) 0, 5, 10, 15
20, 25, 30, 35
Select the time out value for the detection of ATA(PI)
devices
ATA(PI) 80Pin Cable
Detection
Host&Device
Host
Device
Select the mechanism for detecting 80 pin cable
