KTD-S0008-F Page 54 Setup Guide
JRexplus-DC User's Guide
22.5.5.1 Hardware Health Configuration Submenu
Feature Option Description
CPU Temperature N / A Show the CPU diode temperature
CPU Fan Voltage 12.5% ... 25%
87.5% ... 100%
Define CPU fan PWM duty cycle
Fan Speed Divisor 1, 2, 4, 8, 16
32, 64, 128
Select the CPU fan divisor
CPU Fan Speed N / A Show the CPU fan speed
VcoreA N / A Show a system voltage
+1.05Vin N / A see above
+1.8Vin N / A see above
+3.3Vin N / A see above
+5.0VSB N / A see above
+3.3VSB N / A see above
VBAT N / A see above
22.5.5.2 Watchdog Configuration Submenu
Feature Option Description
Watchdog Mode Disabled
Enabled
Select operation mode
Initial Delay Disabled
1s, 5s, 10s, 30s
1:00m, 5:30m
10:30m, 30:30m
Select time until the watchdog counter starts the counting.
Useful to handle longer boot times
Trigger Timeout Disabled
1s, 5s, 10s, 30s
1:00m, 5:30m
10:30m, 30:30m
Select maximum trigger period
22.5.5.3 MPS Configuration Submenu
Feature Option Description
MPS Revision 1.1
1.4
Select MPS (Multi Processor Specification) revision
