KTD-S0008-F Page 63 Appendix A: System Resources
JRexplus-DC User's Guide
A.5 PCI Devices
All devices follow the Peripheral Component Interconnect 2.3 (PCI 2.3) specification. Please see the speci-
fication for more details.
PCI Device PCI IRQ Comment
Host Bridge None Chipset
VGA Graphics INTA Chipset
Graphics Controller None Chipset
HD Audio Controller INTA Chipset
PCI Express Bridge 1 INTA Chipset
USB 1.1 Controller 1 INTA Chipset
USB 1.1 Controller 2 INTB Chipset
USB 1.1 Controller 3 INTC Chipset
USB 1.1 Controller 4 INTD Chipset
USB 2.0 Controller (EHCI) INTA Chipset
PCI Express Bridge 2 None Chipset
ISA Bridge / LPC Controller None Chipset
IDE Controller INTB Chipset
SMBus Controller INTB Chipset
Fast Ethernet Controller INTA Chipset
Gigabit Ethernet Controller INTA Onboard PCI Express device
A.6 System Management Bus (SMBus)
The JRexplus-DC uses an onboard System Management Bus (SMBus). This bus is not available on a peri-
pheral connector and therefore cannot be used for external SMBus devices.
SMBus Address Device Comment
A0h / A1h SPD Eeprom (DDR-SDRAM) Part of the DDR RAM module
E2h / E3h GPIO Controller PHILIPS I/O controller PCA9538
Warning: There are more devices connected to the SMBus than listed in this table but access to these devices is not
permitted. Don’t access any other device addresses except those listed above.
