KTD-S0008-F Page 8 Specifications
JRexplus-DC User's Guide
3.3 Mechanical Specifications
Dimensions
102 x 147 mm (4.0" x 5,8")
Height on top approx. 31 mm
Height on bottom approx. 6 mm
3.4 Electrical Specifications
Supply Voltage
The power supply connector (10 pins) requires +5V, +12V and +5V standby - alternative +5V only mode is
possible.
+5V DC ± 5%
+12V DC ± 5% (only necessary for LCD panel)
+5V DC standby ± 5%
Supply Voltage Ripple
Maximum 100mV peak to peak 0 – 20 MHz
Supply Current (DOS prompt)
Power consumption tests were executed during the DOS prompt with 1 GB DDR2 SDRAM, DVI monitor, USB
keyboard and CF card as boot device (default BIOS settings). The +12VDC line was not measured as this
voltage is only used to supply backlights through the backlight connector J96.
Article number 02008-0000-16-0
Supply voltage 5V
DOS Prompt Soft Off S5
[A] [W] [A] [W]
1,74 8,7 0,15 0,76
