BIOS - Chipset
KTA70M/mITX Users Guide
KTA70M/mITX Users Guide
9.3.1
South Bridge
Please find description of the “SB SATA Configuration”, “SB USB Configuration” and “SB HD Azalia
Configuration” on the following pages.
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Chipset
AMD Reference code Version:
►
SB SATA Configuration
►
SB USB Configuration
►
SB HD Azalia Configuration
Restore AC Power Loss
Trinity PI 1.0.0.8
[Power On]
Options for SATA Configuration.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1227. Copyright © 2012 American Megatrends, Inc
Function
Selection
Description
Restore AC Power Loss
Power Off
Power On
Last State
Select AC Power state when power is re-applied
after a power failure.
