KTD-N0861-B Page 5 System Specification
KTA70M/mITX Users Guide
KTA70M/mITX Users Guide
Memory Memory controller is integrated in the AMD eTrinity FP2 processor.
Features are:
• Compliant with JEDEC DDR3 1.5V and LV-DDR3 1.35V / 1.25 SDRAM (not verified)
specifications
• Supports DDR3 SODIMM 204pin single ranks up to 4GB DRAM technology
• DDR3 1066/1333MT/s (PC3-8500/PC3-10600)
• From 1GB to 2x 8GB maximum (16GB in total)
Notes: Less than 4GB displayed in System Properties using 32bit OS
(Shared Video Memory/PCI resources is subtracted)
ECC not supported
Flash (BIOS) 32Mbit SPI Flash for dual System BIOS.
Security Intel® Integrated TPM 1.2 support
Infineon TPM SLB9635TT1.2 (FW 3.17)
IT8516E
Embedded
Controller
KT Feature Connector.
15 Multiplexed (GPIO, DAC, ADC, PWM & TIMER)
Possible 152 GPIO expansion.
Software Watchdog.
Audio Codec Audio, 7.1 Channel High Definition Audio Codec using the VIA VT1708S codec
Seriel ATA 5x SATA port J9 – J13, SATA 3.0
1x mSATA J39 (mechanically sharing space with mPCIe slot J38), SATA 3.0
• RAID Support (RAID modes 0 and 1)
Frontpanel 2xUSB, HDD-LED, SYSRST#, SUSLED, PWRBTN#, AUDIO Line/MIC output.
PCIe 1x PCI Express x8 Slot (in mechanically x16 slot)
1x PCI Express x4 Slot (in mechanically x16 slot)
1x mPCIe Slot J38 (mechanically sharing space with mSATA slot J39)
DisplayPort 3x DisplayPort connector ( in REAR-IO area)
DP1 J43
DP2 J3
DP0 J4
Optionally Add-On card with 1x DisplayPort
LVDS Optionally Add-On card (TBD)
Audio Jack 3x Audiojacks stack J40 (in REAR-IO area)
Blue Line-In
Green Speaker
Pink Mic
Audio Audio Pin header J41
Line-out
Line-in
Surround output: SIDE, LFE, CEN, BACK and FRONT
Microphone: MIC1 and MIC2
CDROM in
SPDIF (electrical Interface only)
