3.2 KTA70M/mITX Block Diagram
A70M
FCH
2x SODIMM DDR3
Dual Channel 1067/1333
eTrinity APU
Processor
813pin uBGA
PCIe x8 (x16slot) Graphics
3x DP (DisplayPort 1.2)
4x USB3.0/USB2.0
9x USB2.0
VIA Audio Codec
1x PCIe x4 (x16 slot)
1x mPCIe w. USB (USB2.0)
2x 10/100/Gbe
Intel Pearsonville I211AT
5x SATA (SATA3.0, RAID0/1)
1x mSATA
TPM (Infineon)
Embedded
Controller
ITE8516
Feature connector:
SMBus/I2C
GPIO/DAC/ADC/PWM
GPIO expansion (up to 152)
Intruder
SPI BIOS Flash
2x Fan (CPU/System)
2x COM (RS232)
6-pin PS/2 Keyboard/Mouse
