8 lpc connector (j29), Lpc connector (j29) – Kontron KTA70M-mITX User Manual
Page 38
KTD-N0861-B
Page 31
Pin Connectors
KTA70M/mITX Users Guide
KTA70M/mITX Users Guide
7.8
LPC Connector (J29)
The LPC connector is unsupported. The connector is type Foxconn HC11101-P0 or similar.
Note Pull
U/D Ioh/Iol Type
Signal
PIN
Signal
Type Ioh/Iol Pull
U/D Note
-
-
PWR
LPC CLK
1 2
GND
-
-
PWR LPC FRAME#
3
KEY
LPC RST#
5 6
+5V
LPC AD3
7 8
LPC AD2
+3V3
9 10
LPC AD1
LPC AD0
11 12
GND
SMB_CLK
13 14
SMB_DATA
SB3V3
15 16
LPC SERIRQ
GND
17 18
CLKRUN#
SUS_STAT#
19 20
NC
