Hardware Description

28

AT8404 User Guide

www.kontron.com

Gigabit Ethernet

Port 0 and ports 8 to 11 of each AMC are connected to the Ethernet switch. The Ethernet switch supports
1000BASE-BX Gigabit Ethernet.

Storage

Ports 2 and 3 of the AMC slots are reserved for storage connections to other AMC bays or the RTM (see section
3.1.2. Storage Interconnect).

PCI Express

Bays B1 and B3 and bays B2 and B4 implement a x4 direct connection on ports 4 to 7.

Automatic Protection Switching

Port 12 on each AMC bay is used as a 2.5 Gbps direct interconnect to the neighbouring Carrier Board via the
update channel for line card applications.

Interconnects to RTM

Each

AMC Bay has seven generic interconnects to the RTM Zone 3 (ports 13 to 20).

3.1.7 IPMI

The AT8404 supports an intelligent hardware management system based on the Intelligent Platform Manage-
ment Interface (IPMI) Specification 1.5. It provides the ability to manage the power, cooling and intercon-
nect needs of intelligent devices, to monitor events and to log events to a central repository.

The main building blocks of the IPMI architecture of the AT8404 are:

• IPMC Intelligent Platform Management Controller

• FPGA (Field Programmable Gate Array)

3.1.7.1

IPMC

The IPMC controls all hotswap and E-Keying processes required by ATCA. It activates the board power supply
and enables communication with the AMC card and the RTM. The IPMC manages the Ethernet switch E-Keying
and the baseboard ATCA feature. The controller is connected to the ATCA shelf manager via IPMB bus on the
backplane.

All voltages and currents on the base board are monitored by the IPMC, including the management and AMC
supply. Six temperature sensors on the board make sure that thermal conditions are met. Following is a list
of the temperature sensors and their positions. For information on how to obtain sensor values and thresh-
olds, refer to the AT8404 CLI Reference Manual.

Table 3-12: Temperature Sensors

Temperature Sensor

Position

Temp PPC Inlet

Lower board edge, rear third, near Unit Computer

Temp PPC Outlet

Near Unit Computer

Temp AMC Inlet

Lower board edge, middle of AMC area

Temp AMC Outlet

Upper board edge, middle of AMC area

Temp PCB Outlet

Upper board edge, rear third

Temp BCM Outlet

Near GbE switch
