Chipset Setup CP6002 uEFI BIOS
Page 30 ID 1039-1612, Rev. 2.0
3.1.1.3.3.6 OROM UI and BANNER
This function is used to display or hide RAID OptionROM graphical UI and information.
Default setting: Enabled
3.1.1.3.3.7 HDD Unlock
This function is used to indicate that the HDD password unlock in the OS is enabled.
Default setting: Enabled
3.1.1.3.3.8 LED Locate
This function is used to indicate that the LED/SGPIO hardware is attached and the “ping to lo-
cate” feature is enabled on the OS.
Default setting: Enabled
3.1.1.3.3.9 IRRT Only on eSATA
This function is used to indicate that only Intel Rapid Recovery Technology (IRRT) volumes or
any RAID volume can span internal and external SATA.
Default setting: Disabled
SETTING DESCRIPTION
Disabled Use this setting to hide RAID UI and information as long as RAID volumes are normal.
Enabled Use this setting to display RAID UI and information.
SETTING DESCRIPTION
Disabled Use this setting to indicate that the HDD password unlock in the OS is disabled.
Enabled Use this setting to indicate that the HDD password unlock in the OS is enabled.
SETTING DESCRIPTION
Disabled Use this setting to indicate that the LED/SGPIO hardware is attached and the “ping to
locate” feature is disabled on the OS.
Enabled Use this setting to indicate that the LED/SGPIO hardware is attached and the “ping to
locate” feature is enabled on the OS.
SETTING DESCRIPTION
Disabled Use this setting to allow that any RAID volume can span internal and external SATA.
Enabled Use this setting to allow only IRRT volumes to span internal and external SATA.
