HI

n

1710 Manual

Page — 49

APPENDIX A

Command Set (RS-232 Serial Port)

Function

Command Range

Default

Set alarm trigger point

T#

0-9999

-

Set filter number

F#

1-4

1

Set range

R#

1-4

1

Set peak hold (1=ON)

P#

0-1

0

Zero meter

Z

-

-

Initialize system (Reset)

I

-

-

Set 3 or 4 digit display

D#

3-4

3

Set print mode

M#

0-9

2

Set baud rate

B#

12-96

12

Set auto-range (1=ON)

A#

0-1

0

Set quiet mode (1=ON)

Q#

0-1

1

Set command echo (1=ON) E#

0-1

0

Run self test

ST

-

-

Set status line

S#

0-8

-

0

Send system status

1

Send alarm trigger point

2

Send range number

3

Send filter number and filter spec.

4

Send bias voltage

5

Send offset (in milliwatts)

6

Send stim value

7

Send power supply voltages

8

Send current RF reading

Archived 4/2/10
