HI n 1710 Manual Page — 31
R The R command sets the range of the instrument.
The form of the command is R# where # is 1, 2, 3,
or 4. The numbers correspond to the front panel
ranges 1-4 as follows:
Range # Range
1 0-1 mW/cm 2
2 0-2 mW/cm 2
3 0-5 mW/cm 2
4 0-10 mW/cm 2
S The S command can be used to query the HI-1710
as to its status. The form of the S command is S#
where # is a one digit number as follows (refer to
mode 3 earlier in this section for further
information):
0 Send System Status - A line of data is returned
from the HI-1710 summarizing the system
status.
1 Send Alarm Set Point - Displayed in the form:
ALARM --- X.XXX (set point in mW/cm
2 )
2 Send Range Number - The current range or
scale setting is displayed in the form: SCALE ---
X (range 1, 2, 3, 4 relating to the relative
location of the range LED's on the instrument
front panel).
3 Send Filter Number and Specification - The
current filter setting and specification is
displayed in the form (refer to section 2.0
Specifications for filter details):
