Page — 18 HI n 1710 Manual
Offset (shift ALARM SET Decrease [ w ]) - Displays
the probe offset reading. This value should be
between 0.005 and 0.100 volts.
Reset (shift RANGE Increase [>]) - Resets all the
instrument parameters to their default settings and
repeats the self-test. Note that the Alarm Set Point
and Baud Rate do not change on RESET.
Power Supply (shift RANGE Decrease [<]) -
Displays the internal power supply voltages in
sequence:
Voltage Acceptable Range
+4.000 3.995 - 4.005
+5 4.75 - 5.25
+8.00 7.60 - 8.40
-8.00 7.92 - 8.08
3/4 Digit (shift FILTER right [>]) - Alternately
selects 3 or 4 digit display (two or three decimal
places).
Set Baud Rate (shift FILTER left [<]) - Changes the
baud rate of the RS-232 serial communication port.
When the switch is initially activated, the current
baud rate is displayed for two seconds. If the
switch is held, the baud rate will sequence through
its range of values:
1200 - 600 - 300 - 19.2K - 9600 - 4800 - 2400
Release the switch when the desired baud rate is
displayed.
Stim (shift PEAK HOLD) - When activated, applies a
Archived 4/2/10
