Page — 46 HI n 1710 Manual
same direction as IC's U7 and U8, but pin 1 of the IC is
inserted into pin 3 of the socket. This leaves pins 1,2,27,
and 28 of the socket open.
Replacement Parts
The following accessories and parts are available from
Holaday Industries, Inc. and can be installed or replaced
by the user.
P/N
470080
Spacer Cone - the spacer cone controls the
spacing between the detector diode array
and the oven surface. It should be replaced
when worn or dirty to avoid erroneous
readings. To maintain stated accuracy, use
only Holaday Industries, Inc. replacement
cones.
470125 Plastic Shield - protects the spacer cone
when testing and during storage and
transportation.
540113 Spacer Cone Kit - includes 2 cones and 4
shields.
2217500 AC Power Cord
HI-2623 Replacement Probe/Preamp Assembly -
probe/preamp assemblies may be used
interchangeably with the HI-1710. Rather
than remove an instrument from service, a
calibrated assembly may be used to
replace the existing probe with no down
time. Many service problems relate to
damage to the probe or cable and can be
corrected without returning the HI-1710 to
