Introduction

If your K144XV is already installed in your K3, turn to Using the K144XV on page 18 for operating

instructions.

The K144XV option adds 144 to 148 MHz receive and 10-watt transmit capability to your K3 via a separate
antenna connector on the rear panel. Complete specifications and operating instructions are included in your K3
Owner’s manual. This manual covers both installation and operation of the K144XV option.

Only a few basic hand tools are needed (see page 6) to perform the installation. A minimal amount of soldering
is required to install a power connector on the K3 RF board on some K3s.

Specifications

General

Frequency Range:

144-148 MHz

I.F.

Range:

28-30

MHz

Dimensions (HWD):

1x3.2x5 inches (2.5x8.1x12.7 cm)

Supply

Voltage:

13.8

VDC

Typical

Current

Consumption:

Transmit:

Receive: 0.25A

Off:

0.01A

Transmit

Power Output:

8 to10W Typical (13.8 V at the K3 in Transmit. Lower voltages will
reduce the maximum power out)

Spurious Output:

< -60 dBc

Receive

Noise

Figure:

typical

Gain:

typical

Features

PIN diode T/R switching for full QSK

Built-in temperature sensing with automatic over-temperature shut-down

Separate BNC antenna connector on K3 rear panel

Field upgradeable with built-in diagnostic and troubleshooting commands
