M O D E L 2 0 0 I X / 2 5 0 I X U P G R A D E

Drum Installation

Version 1

Model 200iX/250iX Upgrade Installation Guide

1-13

12 Place the air pump spacer (P/N 26152030) as shown in Figure 1-8.

Note: For clarity, the iX drum module is not shown.

Figure 1-8: Installing the Air Pump Spacer

spacer

air pump
