Dynojet 250iX: Upgrade Installation Guide User Manual
Page 13
M O D E L 2 0 0 I X / 2 5 0 I X U P G R A D E
Model 200iX/250iX Upgrade Specifications
Version 1
Model 200iX/250iX Upgrade Installation Guide
1-5
Figure 1-2: Model 250iX Dyno with Accessories
iX Upgrade
Folding Ramp Option
(iX Upgrade)
iX Drum Module
Eddy Current
Brake
High Pressure
Blower
Wheel Clamp
Option
Power Carriage
Option
Folding Ramp Option
(Dyno)
Monitor Support
and Tray
Model 250i Dyno
Trike Carriage
Adapter
