Place ECL-395-X
sign on door
5
Deadlatch
99 strike
4
3
2
free service under normal usage. Periodically inspect and lubricate the unit to
The Detex Value Series® devices are designed to provide many years of maintenance
(use shim if necessary)
Note:
Check device function and
marking and drilling for
machine screws. Tighten
the latchbolt.
Firmly tighten screws
Align the 99 strike with
Install cover with 6-32
strike engagement BEFORE
Care and Maintenance:
extend its life.
center screw.
with hand tools only.
1
Fasten rim device to mounting
plate and door with 1/4-20x1"
machine screws(drill #7 holes)
or #14 self-drilling screws
For Hurricane Models
Protect wires
(see Hurricane kit)
Refer to electromagnetic
lock instructions after
step 4 below.
(packaged with
electromagnetic lock)
Mark and drill center hole.
9/64" for 10-24 machine
screws.
No pilot hole necessary
for #10 self-drilling screws.
(see fastener table)
Secure the 99 strike.
