Page 5
MUST BE INSTALLED!
Insert centercase into slots
of centercase mounting plate,
depress pushpad, rotate
toward door.
1
Position cam as shown
Peel off backing
to expose tape.
DOOR
3
When using Pushpad Wrap with text
Verify wrap is secured
by snapping in place.
Install Pushpad Wrap.
verify handing before installing wrap.
(LHR handing shown)
IMPORTANT:
with 1/4-20 x 1/4" PPH
Fasten rim device
to mounting plate
2
103182 Page 5
