Troubleshooting – Detex Delayed Egress With Magnetic Lock User Manual
Page 14

Alarm sounds immediately when power
is applied:
No green light when key is turned CCW:
No delayed egress:
Both red and green lights on:
Low battery signal-
Two chirps every 45 seconds:
Make sure the key cylinder arming switch is set to 'OFF'.
Confirm strike is pushing in dead latch, door must be closed.
Confirm 24VDC power on the delayed egress device main board terminals 1(+) & 2(-).
Confirm closed fire loop connection on power supply.
Confirm the two black wires on the center case are plugged into the 2-pin header on
the center case circuit board.
Confirm cable is plugged in properly.
Confirm the mortise cylinder is functioning correctly.
Confirm closed fire loop connection on power supply.
Confirm 24VDC power on the delayed egress device main board terminals 1(+) & 2(-).
With the unit armed there should be (30-38VDC without load) on the orange (+) and
blue (-) wires.
The armature plate needs to float. See mag-lock instructions.
The orange wire needs to be wired to terminal 1 in the mag-lock. The blue wire
needs to be wired to terminal 3 in the maglock.
Factory installed jumper removed from terminals 3 & 4.
Check battery. If no battery is needed, slide "DisLoBat" switch to on.
See electrical pages of instructions.
Problem
TROUBLESHOOTING
Probable cause
103182 Page 14
