40 inches above
finished floor
Mark centerline
self-drilling screws
lockwashers and
1/4-20x1" machine
Fasten tightly with
screws or #14
for unit
self-drilling screws
screws or #14
Fasten loosely with
two 1/4-20x1" machine
6
1
Strike holes
Mounting plate Hole
2
Punch marked
holes
4
If necessary, remove
to mark trim hole
Mark mounting plate
and strike holes
label temporarily
hole
Mounting plate
3
Slide 99 strike locator
into mounting plate.
(if using a 98 strike, see
98 STRIKE INSTALLATION page)
Mounting plate holes (2)
For 1/4-20 machine screws drill #7 holes.
For #14 self-drilling screws no pilot holes
necessary.
For sex nuts drill 3/8" holes.
(see fastener table)
Strike holes (2)
For 1/4-20 machine screws
drill #7 holes
No pilot hole necessary
for #14 self-drilling screws
(see fastener table)
if necessary.
(see outside
trim instructions)
Trim input hole
5
RECOMMENDED
103185 Page 4
