Big Book Rack
1x
(23205)
Big Book
Divider
4x
(31060)
Telescoping Extension
1Left, 1 Right
2x
(330141 - Set)
Accessory Rod
Brackets & Knob
1 Left, 1 Right
2x
(23207 - Set)
(23207L)
(23207R)
Square Accessory Rod
1x
(33027)
Round Accessory Rod
1x
(33028)
Tub Rack
1x
(31058)
Front Channel
1 Left, 1 Right
2x
(23209 - Set)
(23209R)
(23209L)
Front Frame
2x
(33029)
Base
2x
(23210)
Stretcher - 27.5”
1 Bottom, 1 Top
1x
(33035)
Middle Frame
Assembly
1x
(33032-Frame)
(23208-Tub Channel)
Rear Frame Upper
2x
(33031)
Top Shelf
1x
(23206)
Before beginning, you should have:
Contents - IS600-0
(numbers in brackets are individual part numbers)
Royal iRover Teaching Center - Parts R
Allen Key -
2x
(43281)
(Not to Scale)
M6 x 40mm
(43240)
17x
M6 x 19mm
8x
(43219)
M6 Lock Washer
19x
(43273)
M8 Lock Washer
12x
(43274)
M6 Barrel Nut
(43272)
12x
Square Nut
(43270)
4x
M6 x 25mm
6x
(43225)
Bag of extra
hardware
1x
Driver for Cordless Drill
(Not to Scale)
1x
(43280)
Optional use for faster assembly
Hardware Actual Size
Bag = (43201)
(numbers in brackets are individual part numbers)
IS600-0
Whiteboard
Support
2x
(Supports -23211)
S-Hook
2x
(31018)
Projector
Your projector may look different
than this representation
1x
Contents - From the Projector Box
VGA Cable
1x Power Cord
1x
A
B
C
D
E
G
F
Rear Frame
Assembly
Stretcher
1x
(33030-Rear Frame
Lower)
(33035-Stretcher)
(33033-Frame Upright)
(23208-Tub Channel)
IS600 - IS700
IS602 - IS702
Power Bar
1x
(25515)
Illustration
Only
