Copernicus IS702 - Manual (Page 31)

IS600-IS700 Series - Version B - December 16, 2013 - Copernicus Educational Products Inc.
23B
Assemble Projector Plate
You will need:
(Not to Scale)
Actual Size:
KK
RR
SS
Projector
Projector Plate
... Continued Epson Powerlite 470, 480 + SB640
Board Side
Back of
Projector
Board Side
Back of Projector
HH
RR
WW
Projector
Projector Plate
RR
Hitachi CP-A220N, CP-A221N + SB660
Board Side
Back of Projector
Back of
Projector
HH
RR
WW
Projector
Projector Plate
Board Side
More Projectors On Next Page...
Proceed to Step 24...
!
DO NOT TIGHTEN BOLTS
Screw until snug only
!
DO NOT
TIGHTEN
BOLTS
Screw until
snug only
Projector Plate
x 1
KK
x 2
RR
x 8
SS WW
x 4
x 2
JJ
x 4
LL
x 4
x 4
PP HH
x 2
PP
PP
KK
RR
SS
Projector
Projector Plate
PP
PP
(M4x10mm)
(M4x20mm)
(M4x30mm)
(M4x25mm)
31
