Copernicus IS702 - Manual (Page 20)

IS600-IS700 Series - Version B - December 16, 2013 - Copernicus Educational Products Inc.
Important - Assembly
Use specified holes according to your projector and board setup
Chart Paper Support
1x
15
UU
x 4 NN
x 2
Assemble Chart Paper Support
You will need:
(Not to Scale)
Actual Size:
AA
x 4
AA
UU
NN
AA
UU
Note: Do not tighten any fasteners unless prompted
Please Note: Tabs must be
positioned towards the back
of the unit and sit behind the
Whiteboard Supports. !
Tab
2 Person Task
Whiteboard
Support
Side View
Bottom
Top
2
3
7
1
Image shown for mounting Chart Paper Support to holes 1 & 2.
Use same technique based on board and projector configuration chart.
AA
UU
AA
UU
NN
4, 6
2, 4
4, 6
2, 4
4, 6
1, 2
4, 6
1, 2
1, 2
Model Projector Holes Board
CP-A220N
CP-A220N
CP-A221N
CP-A221N
CP-A300N
CP-A300N
CP-A301N
CP-A301N
IPJ-AW250N
Smart 640
Smart 660
Smart 640
Smart 660
Smart 640
Smart 660
Smart 640
Smart 660
Copernicus 66” WB
Hitachi
4, 6
1, 2
4, 6
1, 2
4, 6
2, 4
1, 2
4, 6 Powerlite 450W
Powerlite 450W
Powerlite 460
Powerlite 460
Powerlite 470/480
Powerlite 470/480
Brightlink 455Wi
Brightlink 475Wi/485Wi
Smart 640
Smart 660
Smart 640
Smart 660
Smart 640
Smart 660
Copernicus 66” WB
Copernicus 66” WB
Epson
4
5
6
8
9
20
