Copernicus IS702 User Manual
Page 11
IS600-IS700 Series - Version B - December 16, 2013 - Copernicus Educational Products Inc.
Build Rear Frame
You will need:
(Not to Scale)
x 3
x 3
Stretcher
27.5” long x 1
Actual Size:
A
E
5
Rear Frame
Upper x 2
E
A
E
A
A
E
!
Indents facing
top of unit
Assembled
!
Important Note: Look for this Picture
Please note that every hole on the
frame has one side indented. The
orientation of the indent may be very
important at times and will be noted.
Please make sure to orient indent as
instructed to make sure hardware holds
properly.
11
