Copernicus IS702 - Manual (Page 27)

IS600-IS700 Series - Version B - December 16, 2013 - Copernicus Educational Products Inc.
Secure Smartboard Bottom
22A
Actual Size:
EE
x 2
Tab flexes - you must apply
pressure to press it in as you
install the Board !
QQ
x 2
EE
QQ
Proceed to Step 23...
Install Dry Erase Magnetic Board Hardware
19B
Actual Size:
Do not tighten nut on bolt, just
screw so it stays at the tip of
the bolt and leaves a space.
EE
x 2 QQ
x 2
EE
EE
QQ
QQ
You will need:
(Not to Scale)
27
