Copernicus IS702 - Manual (Page 19)

IS600-IS700 Series - Version B - December 16, 2013 - Copernicus Educational Products Inc.
14B
Tub Channel x 4 Open Tub x 2
You will need:
(Not to Scale)
C
x 12 D
x 12 F
x 12
Actual Size:
Stubby Tubby x 2
F
C
D
IS602 or IS702: Install CPU Shelf
Angle tub into
the Channel
Slide
Install Tub Channels
R
x 2
S
x 2
T
x 2
Use 1st and 3rd set of holes
Fasten middle bolt first;
HAND TIGHTEN ONLY
this will make the other
two bolts easier to install. !
Before installing tubs, tighten all fasteners firmly
Top
Bottom
!
2 Person Task
Proceed to Step 15...
25 lbs
Weight Limit
on Shelf
Remove pre-
assembled Tub
Channels on
Middle and
Rear Frame
Assemblies
DO NOT
DISCARD!
!
Use the removed
Tub Channels
from the above
step.
!
10 lbs Weight Limit 5 lbs Weight Limit
R
S
T
19
