Identify the Right and Left Whiteboard Support.
Fasten bottom bolts first
DO NOT OVER TIGHTEN!
Left
Whiteboard
Support
Right
Whiteboard
Support
6
Install Whiteboard Supports
Whiteboard Support x 2
You will need:
(Not to Scale)
x 4 x 4
Actual Size:
A E
Left Side Right Side
Top Mounting hole
!
Left Side
Bottom
Mounting hole
A
A
A
A
E
E
E
E
