Copernicus IR400 - Manual (Page 7)

Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
Short stretcher
2x
Contents - Box 1 - CEPCART0
Leg
2x
Before beginning, you should have:
Back
support
2x
Center
slide
pole
1x
Protective
handle
2x
Support stretcher with spring clips
- chrome
1x
Support stretcher
- grey
1x
Slide frame
1x
Slide handle
1x
Front cover
1x Bottom cover
1x
Projector arm
support
1x
Base
1x
Board mounting
frame - top
1x
Board mounting
frame - bottom
1x
4” swivel
total lock caster
4x
Handle
insert
4x
Lift handle
1x
Upper frame
pre-assembly
1x
Wrenches (2 of Each): 10mm, 13mm, 17mm, 19mm
OR Two adjustable wrenches Rubber mallet
Hardware on following page.
Split black
wire loom
1x
Velcro®
strap
12x
Top clamp
2x
Contents - Box 2 - CEPCART1 or 2
Additional Tools Required
Board mounting
frame - support
2x
Epson Mobile Cart - Base Frame
Epson
CART
Adapter
Plate
1x
7
