Tighten – Copernicus IR400 User Manual
Page 27

Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
You will need:
(not to scale)
15B
Actual Size:
Install Protective Handles for Use With a Side Laptop Arm
Protective handle x 2
Handle insert x 4
M8 lock nut
8x
R
M6 x 19mm
bolt 6x
I
M8 lock washer
6x
V
M6 barrel nut
6x
W
If you plan to install the optional Side Laptop Arm
1
2
R
R
Do not secure handle on the lower right side
(from Front) of the unit. This is where your side laptop
arm will be installed.
3
W
V
I
TIGHTEN!
!
27
