Caution – Copernicus IR400 User Manual
Page 43
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
You will need:
(not to scale)
28
Actual Size:
M6 x 35mm bolt
4x
BB
M6 lock washer
4x
N
Install
Lock Box Stretchers
Optional
Lock box stretcher 1 x 1
Lock box stretcher 2 x 1
Image shown with door
removed for clarity
2
1
Ensure that the cutout
detail for the lock is
oriented to the outside
of the lock box.
Ensure the arrow
is pointing down.
N
N
BB
BB
N
BB
BB
N
Ensure hole in stretcher
is pointing upwards.
CAUTION
Maximum recommended weight in
lock box - 50 lbs.
!
43
