Caution – Copernicus IR400 User Manual
Page 11
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
Partially
threaded M8 x 50mm bolt 2x
Leg x 2
You will need:
(not to scale)
2
K
Attach Legs to Base
!
Ensure legs are aligned the
correct way when looking from the
front or back of the unit.
CAUTION
Maximum recommended weight on
bottom shelf - 50 lbs.
!
Hole indents should
always be to the outside
of the unit.
K
M8 lock washer
2x
V
M8 extra large
flat washer
2x
Y
K
V
Y
K
V
Y
11
