Tighten bolts now – Copernicus IR400 User Manual
Page 31
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
19
Adjust Projector Arm Height
7
6
5
4
3
Install using the bottom two holes on the post. All
the supported projector and board combinations
will use these same post holes.
2
DO NOT fold projector
arm until the projector
has been installed.
!
TIGHTEN BOLTS NOW!
1
Model
Projector
Board
Epson
470/480
470/480
475W/485W
475W/485W
475WI/485WI
480I
475WI/485WI
475WI/485WI
Smart 680
Smart 880
Smart 685
Smart 885
Copernicus 77” WB
Copernicus 77” WB
Egan 90” WB
Egan 96” WB
Epson Projector Arm
PA Post
Holes
1,2
1,2
1,2
1,2
1,2
1,2
1,2
1,2
31
