Snap, Tighten all fasteners on the unit, Warning – Copernicus IR400 User Manual
Page 45
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
30
Install Release Cable
TIGHTEN ALL FASTENERS ON THE UNIT!
SNAP
Front
Release cable runs up behind the
board from the front of the unit.
WARNING
Gas Cylinder is under pressure.
To avoid property damage or bodily
injury, please ensure unit is fully
assembled before adjusting the
height.
!
Hook the bottom of
the cable into the
catch on the
cylinder, and then
snap the body of
cable into the fitting
on the cylinder.
MAKE SURE IT
SNAPS INTO PLACE!
IT IS A VERY TIGHT
SNAP FIT!
